visualizing k-means image segmentation in process
k-meanz clustering of "Les raboteurs de parquet" with k=50 over 5 rounds...
$ python k_means_tf.py ~/Downloads/caillebotte_floor_strippers.jpg -k50 -r5 --data_saving=T --generate_all=T
INPUT, via Gustave Caillebotte:
In [1]:
%matplotlib inline
import os
import re
import matplotlib.pyplot as plt
from mpl_toolkits.mplot3d import Axes3D
import matplotlib.image as mpimage
from matplotlib import animation
import numpy as np
In [2]:
# load paths/to/relevant/files
pwd = os.path.abspath('.')
data_dir = os.path.join(pwd, 'data')
img_dir = os.path.join(pwd,'imgs')
# parse directory for centroid, cluster_size datafiles
d_centroids, d_clust_size = {}, {}
filetypes = {'roids': d_centroids, 'cluster_size': d_clust_size}
for ftype, fdict in filetypes.iteritems():
pattern = re.compile(r'(?P<file>.*[^_]*_(?P<round>.*)\.{}\.txt$)'.format(ftype))
matches = (re.search(pattern, f) for f in os.listdir(data_dir))
for m in matches:
try:
fdict[m.group('round')] = m.group('file')
except:
continue
# ..and dims datafile
pattern = re.compile(r'.*\.dims\.txt$')
matches = (re.search(pattern, f) for f in os.listdir(data_dir))
for m in matches:
try:
img_dims = m.group(0)
break # one file only
except:
continue
# ..and corresponding images
d_imgs = {}
pattern = re.compile(r'(?P<file>.*[^_]*_(?P<round>.*)\.jpg$)'.format(ftype))
matches = (re.search(pattern, f) for f in os.listdir(img_dir))
for m in matches:
try:
d_imgs[m.group('round')] = m.group('file')
except:
continue
In [3]:
# Utils to load data by clustering round
with open(os.path.join(data_dir, img_dims), 'r') as f:
dims = np.loadtxt(f)
def loadData(r):
r = str(r)
with open(os.path.join(data_dir, d_centroids[r]), 'r') as f:
centroids = np.loadtxt(f)
if r == 'init':
clust_size = None
else:
with open(os.path.join(data_dir, d_clust_size[r]), 'r') as f:
clust_size = np.loadtxt(f)
centroids_yx, centroids_rgb = centroids[:,:2], centroids[:,2:]
return (centroids_yx, centroids_rgb, clust_size)
def loadImage(r):
r = str(r)
with open(os.path.join(img_dir, d_imgs[r]), 'r') as f:
return mpimage.imread(f)
height, width, ratio = dims
ROUND = '0'
In [12]:
fig = plt.figure()
ax = fig.add_subplot(111)
image = loadImage(ROUND)
# scale plot by factor N
N = 1.4
params = plt.gcf()
figDims = fig.get_size_inches()
params.set_size_inches(N*dim for dim in figDims)
ax.set_title('Round {}'.format(ROUND), fontsize=14, y=1.05)
plt.axis("off")
plt.imshow(image)
Out[12]:
@ round 0: where are clusters in colorspace ? pixels per cluster ?
In [5]:
centroids_yx, centroids_rgb, clust_size = loadData(ROUND)
# unpack centroid color data
R,G,B = [np.array(vals, dtype=np.int32) for vals in zip(*centroids_rgb)]
# normalize RGB to [0,1]
colors = [np.array(pt)/255. for pt in centroids_rgb]
In [29]:
fig = plt.figure()
ax = fig.add_subplot(111, projection='3d')
# set axis ranges for colorspace
colorspace = [0,255]
ax.set_xlim(colorspace)
ax.set_ylim(colorspace)
ax.set_zlim(colorspace)
# set maximum point area
MAX_AREA = 500
r = MAX_AREA/max(clust_size)
# scale plot by factor N
N = 1.3
params = plt.gcf()
figDims = fig.get_size_inches()
params.set_size_inches(N*dim for dim in figDims)
# add figure text
#fig.suptitle('Round {}'.format(ROUND), fontsize=14, fontweight='bold')
ax.set_xlabel('R', color='red', fontsize=12)
ax.set_ylabel('G', color='green', fontsize=12)
ax.set_zlabel('B', color='blue', fontsize=12)
# but remove tick labels
ax.set_xticklabels([])
ax.set_yticklabels([])
ax.set_zticklabels([])
# add figure text
#ax.set_title('Round {}'.format(ROUND), fontsize=14, y=1.05)
ax.scatter(R, G, zs = B, c = colors, s = r*clust_size)
Out[29]:
... in image space ?
In [30]:
# unpack centroid location data
y,x = [np.array(vals) for vals in zip(*centroids_yx)]
In [31]:
fig = plt.figure()
ax = plt.gca()
# set maximum point radius
MAX_RADIUS = 500
r = MAX_RADIUS/max(clust_size)
ax.scatter(x, y, c = colors, s = r*clust_size)
#ax.scatter(x, y, c = colors)
# scale axes to image size (scaled if clustering scaled)
ax.set_xlim([0,width*ratio])
ax.set_ylim([0,height*ratio])
# set origin to top left, as per image array
ax.invert_yaxis()
ax.xaxis.tick_top()
# scale plot by factor N
N = 1.4
params = plt.gcf()
figDims = fig.get_size_inches()
params.set_size_inches(N*dim for dim in figDims)
# with image
image = loadImage(ROUND)
plt.imshow(image, extent=[0,width*ratio,height*ratio,0], alpha=0.8)
# add figure text
#fig.suptitle('Round {}'.format(ROUND), fontsize=14, y=1.05)
Out[31]:
clustering over 5 rounds = let's make some movies.
In [32]:
# vid utils
def video_inline(fname, options=['controls','autoplay','loop']):
"""Util to embed videos inline"""
from IPython.display import HTML
mimetype = os.path.splitext(fname)[-1].replace('.','')
video_encoded = open(fname, "rb").read().encode("base64")
tags = ' '.join(options)
video_tag = '<video {} src="data:video/{};base64,{}">'.\
format(tags, mimetype, video_encoded)
return HTML(data = video_tag)
def ani2vid(ani, outfile, options=None):
"""Save animation to file and display inline"""
ani.save(outfile, fps=0.2, writer=animation.FFMpegWriter(),
extra_args=['-vcodec', 'libx264', '-pix_fmt', 'yuv420p'])
# avoid displaying initial frame below vid
plt.close(ani._fig)
return video_inline(outfile, options) if options else video_inline(outfile)
In [33]:
# set up permanent parts of fig
fig = plt.figure()
ax = fig.add_subplot(111, projection='3d')
# set axis ranges for colorspace
colorspace = [0,255]
ax.set_xlim(colorspace)
ax.set_ylim(colorspace)
ax.set_zlim(colorspace)
# set maximum point area
#MAX_AREA = 500
# TODO: make constant ?
#r = MAX_AREA/max(clust_size)
# currently: r is set by previous ratio in example above (ROUND 0: ~0.02)
# scale plot by factor N
N = 1.3
params = plt.gcf()
figDims = fig.get_size_inches()
params.set_size_inches(N*dim for dim in figDims)
# add figure text
#fig.suptitle('Round {}'.format(ROUND), fontsize=14, fontweight='bold')
ax.set_xlabel('R', color='red', fontsize=12)
ax.set_ylabel('G', color='green', fontsize=12)
ax.set_zlabel('B', color='blue', fontsize=12)
# but remove tick labels
ax.set_xticklabels([])
ax.set_yticklabels([])
ax.set_zticklabels([])
scat = ax.scatter([], [], zs=[], s=[], c=[])
def init():
# TODO: randomly intialized centroids ?
#centroids_yx, centroids_rgb, clust_size = loadData('init')
#data = centroids_rgb
#R,G,B = [np.array(vals, dtype=np.int32) for vals in zip(*data)]
# normalize RGB to [0,1]
#colors = [np.array(pt)/255.0 for pt in data]
#scat._offsets3d = (R, G, B)
return scat,
# define update function for each round
def update(i):
_, centroids_rgb, clust_size = loadData(i)
# get centroid color data
R,G,B = [np.array(vals, dtype=np.int32) for vals in zip(*centroids_rgb)]
# normalize RGB to [0,1]
colors = [np.array(pt)/255. for pt in centroids_rgb]
# normalize sizes by ratio r
sizes = r*clust_size
# because of nonsense about changing color on 3D plots,
# instead reset axis and redraw new scatter each round
global scat
scat.remove()
scat = ax.scatter(R, G, zs=B, c=colors, s=sizes)
# return with commma to make iterable (necessary for blit=True)
return scat,
OUTFILE = 'ani_rgb.mp4'
ani = animation.FuncAnimation(fig, update, init_func=init,
frames=5, interval=100000, blit=True,
repeat=True, repeat_delay=5000)
ani2vid(ani, OUTFILE)
Out[33]:
In [1006]:
# set up new fig
fig = plt.figure()
ax = plt.gca()
# set maximum point radius
#MAX_RADIUS = 500
#r = MAX_RADIUS/max(clust_size)
# scale axes to image size (scaled if clustering scaled)
ax.set_xlim([0,width*ratio])
ax.set_ylim([0,height*ratio])
# set origin to top left, as per image array
ax.invert_yaxis()
ax.xaxis.tick_top()
# scale plot by factor N
N = 1.3
params = plt.gcf()
figDims = fig.get_size_inches()
params.set_size_inches(N*dim for dim in figDims)
scat = ax.scatter([], [])
def init():
return scat,
def update(i):
centroids_yx, centroids_rgb, clust_size = loadData(i)
# get centroid location data
y,x = [np.array(vals) for vals in zip(*centroids_yx)]
# get centroid color data
R,G,B = [np.array(vals, dtype=np.int32) for vals in zip(*centroids_rgb)]
# normalize RGB to [0,1]
colors = [np.array(pt)/255. for pt in centroids_rgb]
# normalize sizes by ratio r
sizes = r*clust_size
global scat
scat.remove()
scat = ax.scatter(x, y, c=colors, s=sizes)
return scat,
OUTFILE = 'ani_xy.mp4'
ani = animation.FuncAnimation(fig, update, init_func=init, #fargs=(scat),
frames=5, interval=100000, blit=True,
repeat=True, repeat_delay=5000)
ani2vid(ani, OUTFILE)
Out[1006]:
In [34]:
# set up new fig
fig = plt.figure()
ax = plt.gca()
# scale plot by factor N
N = 1.5
params = plt.gcf()
figDims = fig.get_size_inches()
params.set_size_inches(N*dim for dim in figDims)
# hide axis
plt.axis("off")
# add figure text
title = ax.set_title('', fontsize=14, y=1.05)
im = plt.imshow(np.empty_like(loadImage(ROUND)))
def init():
return im,
def update(i):
image = loadImage(i)
im.set_array(image)
title.set_text('Round {}'.format(i))
return im,title
OUTFILE='ani_imgs.mp4'
ani = animation.FuncAnimation(fig, update, init_func=init,
frames=5, interval=1000, blit=True,
repeat=True, repeat_delay=500000, save_count=10000000000)
ani2vid(ani, OUTFILE, ['controls', 'autoplay'])
Out[34]:
In [35]:
# all together now: centroid locations, overlaid on image, with round #
# set up new fig
fig = plt.figure()
ax = plt.gca()
# set maximum point radius
#MAX_RADIUS = 500
#r = MAX_RADIUS/max(clust_size)
# scale axes to image size (scaled if clustering scaled)
ax.set_xlim([0,width*ratio])
ax.set_ylim([0,height*ratio])
# set origin to top left, as per image array
ax.invert_yaxis()
ax.xaxis.tick_top()
# scale plot by factor N
N = 2.0
params = plt.gcf()
figDims = fig.get_size_inches()
params.set_size_inches(N*dim for dim in figDims)
scat = ax.scatter([], [])
im = plt.imshow(np.empty_like(loadImage(ROUND)),
extent=[0,width*ratio,height*ratio,0],
alpha=0.95)
#title = ax.set_title('', fontsize=14, y=1.05)
def init():
return scat,im#,title
def update(i):
centroids_yx, centroids_rgb, clust_size = loadData(i)
# get centroid location data
y,x = [np.array(vals) for vals in zip(*centroids_yx)]
# get centroid color data
R,G,B = [np.array(vals, dtype=np.int32) for vals in zip(*centroids_rgb)]
# normalize RGB to [0,1]
colors = [np.array(pt)/255. for pt in centroids_rgb]
# normalize sizes by ratio r
sizes = r*clust_size
global scat
scat.remove()
scat = ax.scatter(x, y, c=colors, s=sizes)
im.set_array(loadImage(i))
#title.set_text('Round {}'.format(i))
return scat,im#,title
OUTFILE = 'ani_xy_img.mp4'
ani = animation.FuncAnimation(fig, update, init_func=init, #fargs=(scat),
frames=5, interval=100000, blit=True,
repeat=True, repeat_delay=5000)
ani2vid(ani, OUTFILE)
Out[35]:
